Product Details:
|
| Material: | Graphite | Advantage: | Long Service Life |
|---|---|---|---|
| Usage: | Copper And Copper Alloys | Product Name: | Graphite Die |
| Packaging: | Wooden Box | Size: | Customized |
| Shape: | Customized | Port: | Qingdao |
| High Light: | Continuous Casting Graphite Die Mold,Pyrolytic Graphite Die Mold,Continuous Casting Mold For Copper |
||
Purity Quality Pyrolytic Continuous Casting Graphite Die Mold For Copper Brass Bronze
Product details :
Introduction of Purity Quality Pyrolytic Continuous Casting Graphite Die Mold For Copper Brass Bronze
Graphite dies has a widely used in copper & copper alloys, due to its superior performance. For example, In vertical continuous casting method, graphite dies are applied for producing copper and copper alloys rods and tubes, In horizontal continuous casting method, graphite dies are applied for production of copper and copper alloys section, especially band or strip, and In other related copper & copper alloy casting method, graphite protection sleeves, graphite stoppers, graphite spouts and so on
Purity Quality Pyrolytic Continuous Casting Graphite Die Mold For Copper Brass Bronze materials:
| Properties | Unit |
Numerical value |
| Bulk Density |
g/cm3 |
1.83 |
| Specific Resistance |
μΩ-m |
15 |
| Ash Content | ppm | 50 |
| Porosity | % | 17 |
| Compressive Strength | Mpa | 72.6 |
*Value might be changed due to material size
**Ash value according to purity specifications
Typical property Data JC-510
*Value might be changed due to material size
| Property | Unit | Value |
| Bulk density | g/cm3 | 1.85 |
| Specific electrical resistivity | µΩm | 11 |
| Young's modulus (dynamic measurement) | Gpa | 10.8 |
| Flexural strength | Mpa | 49 |
| Shore hardness | 58 | |
| C.T.E | X10-6/°C | 5.5 |
| Thermal conductivity | W/mk | 116 |
*Value might be changed due to material size
Graphite advantages:
Because of the high tempearture resistance, thermal conductivity, corrosion resistance and special thermal shock resistance, graphite is widely used in metallurgy, mechanical, electrial, chemical, textile, denfense and other industries.
1. High strength. As the temperature rises, the graphite strength increases
2. High temperature resistance
3. Good heat shock resistance
4. Anti-oxidation
5. Strong corrosion resistance to acid and alkali liquid
6. Good conductivity and thermal efficiency.
7. Excellent chemical stability
8. High heat conductivity
9. Mechanical shock resistance
10. Small thermal expansion coefficient
Production environment:
Our company is the professional manufacturer and exporter for graphite products. our company was established at 2008.Our factory is located in Qingdao city. We believe that due to our high quality graphite material and formed graphite parts at very competitive prices with professional service,broad product knowledge and technical expertise can help you save much resource and improve your efficiency,and satisfy more of your customers' needs.
