Square 49Mpa Carbon Graphite Plate Chemical Industry

Square 49Mpa Carbon Graphite Plate Chemical Industry
Square 49Mpa Carbon Graphite Plate Chemical Industry Square 49Mpa Carbon Graphite Plate Chemical Industry

Large Image :  Square 49Mpa Carbon Graphite Plate Chemical Industry

Product Details:
Place of Origin: Qingdao
Brand Name: JC
Certification: JC
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Wooden box
Delivery Time: 10 work days
Payment Terms: T/T
Supply Ability: 10000PC

Square 49Mpa Carbon Graphite Plate Chemical Industry

Description
Material: Carbon Graphite Sample: Available
Package: Wooden Box Type: Customized
Shape: Square,Plate Name: Supply High Density Customized Carbon Graphite Plate
High Light:

49Mpa Carbon Graphite Plate

,

49Mpa graphite sheets plates

,

10.8Gpa Carbon Graphite Plate



High Quality Customized Carbon Graphite Plate



Products details:

Graphite plate has good conductivity, high temperature resistance, acid, alkali corrosion and easy to process.
It is widely used in metallurgy,
Used in chemical industry
Used in electrochemical industry.



Product features:
1. The processing materials are ultrafine granule structure, high purity and graphite with high graphitization degree.
2. High hardness, good anti-oxidation performance and high machining accuracy
3. Good conductivity, high resistivity, sufficient mechanical strength
4. Small porosity and dense structure.
5. Excellent thermal shock resistance, conductive and thermal conductivity.
6. High temperature resistance, corrosion resistance, acid and alkali resistance, good wear resistance.
7. Surface can be treated with anti-oxidation.





About Materials:

Typical property Data JC-Molded graphite
Properties Unit



Numerical value

Bulk Density



g/cm3

1.83
Specific Resistance



μΩ-m

15
Ash Content ppm 50
Porosity % 17
Compressive Strength Mpa 72.6

























*Value might be changed due to material size







JC-G347

Property Unit Value
Bulk density g/cm3 1.85
Specific electrical resistivity µΩm 11
Young's modulus (dynamic measurement) Gpa 10.8
Flexural strength Mpa 49
Shore hardness   58
C.T.E X10-6/°C 5.5
Thermal conductivity W/mk 116



























*Value might be changed due to material size



Typical property Data JC-GSK

Property Unit Value
Bulk density g/cm3 >=1.72
Specific electrical resistivity µΩm <=8.5
Max. grain size mm 0.8
Flexural strength Mpa >=13.5
Compressive strength Mpa >=30
C.E.T X10-6 <=2.5























*Value might be changed due to material size







Graphite advantages:

Because of the high tempearture resistance, thermal conductivity, corrosion resistance and special thermal shock resistance, graphite is widely used in metallurgy, mechanical, electrial, chemical, textile, denfense and other industries.
1. High strength. As the temperature rises, the graphite strength increases
2. High temperature resistance
3. Good heat shock resistance
4. Anti-oxidation
5. Strong corrosion resistance to acid and alkali liquid
6. Good conductivity and thermal efficiency.
7. Excellent chemical stability
8. High heat conductivity
9. Mechanical shock resistance
10. Small thermal expansion coefficient

We can machine various types of graphite connector according to customers' designs.

Production emvironment:

Square 49Mpa Carbon Graphite Plate Chemical Industry 0Square 49Mpa Carbon Graphite Plate Chemical Industry 1Square 49Mpa Carbon Graphite Plate Chemical Industry 2Square 49Mpa Carbon Graphite Plate Chemical Industry 3

Square 49Mpa Carbon Graphite Plate Chemical Industry 4

Square 49Mpa Carbon Graphite Plate Chemical Industry 5

Our company is the professional manufacturer and exporter for graphite products. our company was established at 2008.Our factory is located in Qingdao city. We believe that due to our high quality graphite material and formed graphite parts at very competitive prices with professional service,broad product knowledge and technical expertise can help you save much resource and improve your efficiency,and satisfy more of your customers' needs.
