125Mpa Graphite Raw Material

China Qingdao Jiacheng Graphite Products Co., Ltd. certification
I'm Online Chat Now

125Mpa Graphite Raw Material

125Mpa Graphite Raw Material
125Mpa Graphite Raw Material 125Mpa Graphite Raw Material

Large Image :  125Mpa Graphite Raw Material

Product Details:
Place of Origin: Qingdao
Brand Name: JC
Certification: JC
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiable
Packaging Details: wooden box and vacuum packing
Delivery Time: 5-8 work days
Payment Terms: T/T
Supply Ability: 50000PC

125Mpa Graphite Raw Material

Mateial: Chinese Graphite Material: Foreign Graphite
Size: Customized Package: Wooden Box And Vacuum Packing
Deliver Time: 5-8 Work Days Port: Qingdao Port
High Light:

125Mpa Graphite Raw Material


125Mpa isostatic graphite block


5ppm Graphite Raw Material

High Purity Carbon Graphite Block

Product details :


High Purity Carbon Graphite Block materials:

We can machine various types according to customers' designs.

Typical property Data JC-510

Property Unit Value
Bulk density g/cm3 1.83
grain size um 10
Aperture um 1.5
Specific electrical resistivity µΩm 13
Young's modulus (dynamic measurement) Gpa 11.5
Flexural strength Mpa 60
compressive strength Mpa 125
Shore hardness   95
Thermal expansion(20-200℃) X10-6K-1 4
Thermal conductivity W/mk 100
Ash value ppm 5

*Value might be changed due to material size





Graphite advantages:

Because of the high tempearture resistance, thermal conductivity, corrosion resistance and special thermal shock resistance, graphite is widely used in metallurgy, mechanical, electrial, chemical, textile, denfense and other industries.
1. High strength. As the temperature rises, the graphite strength increases
2. High temperature resistance
3. Good heat shock resistance
4. Anti-oxidation
5. Strong corrosion resistance to acid and alkali liquid
6. Good conductivity and thermal efficiency.
7. Excellent chemical stability
8. High heat conductivity
9. Mechanical shock resistance
10. Small thermal expansion coefficient


Production environment:

125Mpa Graphite Raw Material 0

125Mpa Graphite Raw Material 1

125Mpa Graphite Raw Material 2

125Mpa Graphite Raw Material 3

125Mpa Graphite Raw Material 4

125Mpa Graphite Raw Material 5

125Mpa Graphite Raw Material 6

Our company is the professional manufacturer and exporter for graphite products. our company was established at 2008.Our factory is located in Qingdao city. We believe that due to our high quality graphite material and formed graphite parts at very competitive prices with professional service,broad product knowledge and technical expertise can help you save much resource and improve your efficiency,and satisfy more of your customers' needs.
